A c c e s s o r i e s f o r L A V A
Type
eTWIST
eTOUCH-eco
eTOUCH wifi
eTOUCH mini
ET-14A
ET-111C
FAULTS
Device does not heat:
› Has the fuse been triggered or is it defective?
› Is the external switch in the supply line switched off?
› Is the setpoint temperature of the room temperature con-
troller set lower than the actual temperature of the room?
D E V I C E R A T I N G P L A T E S
The rating plate contains the type-specific technical data. Depending on the arrangement (vertically or horizontally), the rating
plate of the device is placed at the top or on the left on the device.
LAVALITE-GL-700-PW
700 W | IP 55
Landesstraße 16
230 V | 50 Hz
A-5302 Henndorf
15 kg
Made in Austria
Dimensional drawing: nameplate LAVA
I N F O R M A T I O N O N E N E R G Y C O N S U M P T I O N
In combination with an eco-design compliant thermostat, the product specifications comply with EU directive regulations on the
environmentally friendly design of energy-related products (ErP).
G E N E R A L W A R R A N T Y C O N D I T I O N S
Dear customer,
Please observe our general terms and conditions. Country-specific legal entitlements apply to warranty claims; please assert
such rights directly through your distributor.
ATTENTION: Many old electrical and electronic devices contain valuable materials. However, they can also contain harmful substances which
were required for their operation and safety. Such substances may damage the environment if disposed of in residual waste or handled incor-
rectly. Please help us to protect the environment! Do not place your old devices in the residual refuse. Dispose of your old device in accordance
with applicable local regulations. Properly dispose of packaging material, replaced parts and/or components.
RESERVATION: We reserve the right to make technical changes. Modifications, errors and misprints shall not constitute grounds for damages.
® L I T E
Art. no. Description
40517 Switch mounted thermostat with control dial and app function via Bluetooth 4.2, 16 A, 5-28 °C, white
40511 Switch mounted thermostat with touch pad, 16 A, 5-35 °C, white
44722 Switch mounting thermostat with touch pad and Wi-Fi function, 16 A, 5-40 °C, white
39300 Switch mounted thermostat with white touch pad, 16 A, 5-40 °C
40595 Radio room thermostat, LCD display with clock and weekly program
40039 Wireless receiver with 10 A relay in flush-mounted box
Do not cover!
Nicht abdecken!
LITE
®
Radiation heat too low:
› Is the distance between the radiation heater and the person
too large?
› Has the device size been selected too small?
› Are there objects placed between the radiation heater and
the person?
