Comfort Sling Low/Comfort Sling High - human care Basic sling Net Manuel De L'utilisateur

Comfort Sling Low/Comfort Sling High

Product Description
The Human Care Comfort Sling low 25060 and Comfort Sling high 25065 (with neck
support) have one undivided leg section. This means that they can be fitted when the
patient is lying down.
The 25060 and 25065 slings are made from high-friction, cotton-like polyester. As a result
of the friction, the sling moves relatively little in relation to the patient and to the chair.
The 25060 and 25065 slings are designed for two- and four-point suspension.
Technical specifications
Item Part no.. Size
Comfort Sling low 25060-JM Junior medium Grey
Comfort Sling low 25060-S Small
Comfort Sling low 25060-M Medium
Comfort Sling low 25060-L Large
Comfort Sling low 25060-XL Extra large
Comfort Sling high 25065-S Small
Comfort Sling high 25065-M Medium
Comfort Sling high 25065-L Large
Comfort Sling high 25065-XL Extra large
* The weights given are only guidelines and are not a substitute for individual tests. Discrepancies can occur.
Intended use
Lifting the patient from a lying position
1. Lay the patient on his/her side. Position
the sling so that the centre of the sling
lines up with the patient's spine. Take
note of the marking on the sling (outside
up). The bottom part of the sling must
be behind the patient's knees. Roll the
patient over onto his/her other side and
pull the sling through. Lay the patient
on his/her back. If the bed is height-
adjustable, it is a good idea to raise the
head of the bed so that the patient is in a
semi-sitting position.
2. Lower the lift/hanger bar to the height
of the patient's stomach. Attach the back
section and leg section lifting straps to
the lift bar. Hold the lift away from the
patient's face with one hand as you raise
it above the patient's head.
12 www.humancaregroup.com
A (mm/ B (mm/ C (mm/
Colour
inch) inch) inch)
code
360/14.2 750/29.5 900/35.4
Red 360/14.2 750/29.5 1000/39.4
Yellow 480/18.9 850/33.5 1100/43.3
Green 560/22.0 950/37.4 1150/45.3
Blue 640/25.2 1050/41.3 1200/47.2
Red 360/14.2 750/29.5 1210/47.6
Yellow 480/18.9 850/33.5 1330/52.4
Green 560/22.0 950/37.4 1390/54.7
Blue 640/25.2 1050/41.3 1450/57.1
Comfort sling low
Patient's weight*
Weight capacity
kg/lbs
20-35/44-77 250 kg / 551 lbs.
30-60/66-132 250 kg / 551 lbs.
55-90/121-198 250 kg / 551 lbs.
85-120/187-265 250 kg / 551 lbs.
110-140/242-309 250 kg / 551 lbs.
30-60/66-132 250 kg / 551 lbs
55-90/121-198 250 kg / 551 lbs
85-120/187-265 250 kg / 551 lbs
110-140/242-309 250 kg / 551 lbs
3. Pause in this position and check that all
the lifting straps are securely attached to
the hooks.
4. Continue lifting the patient. It may be
necessary to lower the bed slightly. Raise
the patient's legs slightly while turning
him/her away from the bed. It is a good
idea to put your arm around the patient
while you are moving him/her to create a
greater sense of security.
Comfort sling high
Comfort sling low
Comfort sling high
