Full Body Sling/Full Body Sling Net - human care Basic sling Net Manuel De L'utilisateur

Full Body Sling/Full body Sling net

Product Description
The Human Care Full Body Sling and Full body sling net are designed primarily for moving people who need full body support.
The sling puts the patient in a reclining position which reduces the load on the patient's legs.
The Slings are designed for two-, three- and four-point suspension.
Technical specifications
Item Part no..
Full Body Sling 25010-S
Full Body Sling 25010-M
Full Body Sling 25010-L
Full Body Sling 25010-XL
Full Body Sling 25010-XXL
Full Body Sling 25010-XXXL
Full Body Sling Net 25005-S
Full Body Sling Net 25005-M
Full Body Sling Net 25005-L
Full Body Sling Net 25005-XL
* The weights given are only guidelines and are not a substitute for individual tests. Discrepancies can occur.
Intended use
Lifting the patient from a lying position
1. Lay the patient on the side. Position the
sling so that the centre of the sling lines
up with the patient's spine. Take note of
the marking on the sling (outside up). The
bottom part of the sling must be directly
under the patient's coccyx.
Roll the patient over to the other side and pull
the sling through. Lay the patient on the back.
If the bed is height-adjustable, raise the head
of the bed so that the patient is in a semi-
sitting position.
2. Pull the leg sections through between the
patient's legs. Lower the lift to the height of
the patient's stomach. If required, you can
thread the left leg section through the loop
on the outside of the right leg section. Attach
the leg section lifting straps to the leg hooks
on the lift. Turn the lift around, attach the back
section lifting straps to the lift bar. Hold the lift
away from the patient's face with one hand as
you raise the lift.
Alternative: The sling can also be used for
two- or four-point suspension. In this case
the loop on the right leg section is not used.
Instead the leg sections are crossed.
10 www.humancaregroup.com
A (mm/
Colour
Size
inch)
code
Small Red 280/11.0
Medium Yellow 330/12.9
Large Green 380/14.9
Extra large Blue 440/17.3
Extra extra large White 460/18.1
Extra extra extra large Pink 510/20.1
Small Red 280/11.0
Medium Yellow 310/12.2
Large Green 350/13.8
Extra large Blue 380/14.9
B (mm/ C (mm/
Patient's weight*
inch) inch)
kg/lbs
840/33.1 880/34.6 30-60/66-132
910/35.8 940/37.0 55-90/121-198
970/38.2 990/38.9 85-120/187-265
1040/40.9 1050/41.3 110-140/242-309
1120/44.1 1070/42.1 140-200/309-440 300 kg/ 661 lbs
1130/44.4 1050/41.3 190-300/419-660
660/25.9 880/34.6 30-60/66-132
790/31.1 940/37.0 55-90/121-198
920/36.2 990/38.9 85-120/187-265
1060/41.7 1045/41.1 110-140/242-309
3. Pause in this position and check that all
the lifting straps are securely attached to
the hooks.
4. Continue lifting the patient. It may be
necessary to lower the bed slightly. Raise
the patient's legs slightly while turning him/
her away from the bed. It is a good idea
to put your arm around the patient while
you are moving him/her to create a greater
sense of security.
Weight
capacity
250 kg/ 551 lbs
250 kg/ 551 lbs
250 kg/ 551 lbs
250 kg/ 551 lbs
Full body sling
300 kg/ 661 lbs
250 kg/ 551 lbs
250 kg/ 551 lbs
250 kg/ 551 lbs
250 kg/ 551 lbs
Full Body Sling net
