Technical Data

Touch-Operation:
Foot pedal-Operation*:
Status display:
Thermocontrol:
Sterilization at start up:
Annealing tube
Quartz glass:
Safety features
Residual heat display:
Automatic unit switch off:
Temperature monitor:
Electrical
Power supply:
Power consumption:
Protection class:
Heat source:
Mechanical
Quartz glass annealing tube:
Casing:
Measurements (w x h x d):
Weight:
Information on radiation
Emission limit:
Licences
CE:
EU Guidelines:
Protected Design:
26
start of the sterilization (10 sec.) / stop of the sterilization
start of the sterilization (10 sec.) / stop of the sterilization
optical display of the sterilization progress
dynamic sterilization timer, reduces the activation of the
IR-halogen lamp according to the residual heat
automatically sterilization after the device is switched on
750°C - 1000°C (1382°F - 1832°F) sterilization temperature
indicates a hot annealing tube
after 15 minutes without operation
thermal circuit breaker and fan overrun when switching off
the device
Art. No.: 4.101.000:
Art. No.: 4.102.000:
Art. No.: 4.103.000:
approx. 600 W / short time (5 - 10 seconds)
IP 20
IR-halogen lamp
outer-Ø 19 mm, inner-Ø 16 mm, length 112 mm
heat resistant glass / stainless steel
UV and solvent resistant
110 x 170 x 180 mm
approx. 1800 g
The emission limit "risk free" is respected.
The device is assigned to the risk free group
according to EN 62471
EN 61326-1, EN 61010-1, EN 61010-2-010, EN 62471
2014/30/EU, 2014/35/EU, 2011/65/EU, 2006/25/EG
U DE 20 2016 101 067
(*foot pedal is optional)
220 - 240 V 50/60 Hz 2.6 A
112 - 128 V 50/60 Hz 5.1 A
95 - 105 V 50/60 Hz 6 A
