Sterimax basic Mode D'emploi page 16

Read these operating instructions carefully to familiarize yourself with the product before
using. Keep the manual in a safe place for future reference.
Fig. A Fig. A
5
6 6
7 - Ventilation grilles
8 - Fan
9 - Drill hole for replacing annealing tube
10 - Connector for foot pedal
11 - Fuse holder
12 - Power socket
13 - Power switch
14 - Connector
15 - Power plug
16 - Power cable
Fig. C
16
16
4, 4a
3
2
1a 1b
1a - Start symbol - Touch panel
1b - Stop symbol - Touch panel
2 - Status display: sterilization progress
3 - Residual heat display
4 - Quartz glass annealing tube /
annealing tube
4a - Sterilzation orifice
5 - Warning symbol "Hot Surface"
6 - Magnets (inside) for optional tray
Fig. B
7
10
12
14
15
11 8
9
13
