Terminal of
brand
connector
1 ( )
2
3
8.

Assembly Instructions

8.1 Connect the power-switch plug to a correspondingly programmed actuator output of
an electronic module.
8.2 Connect the actuator connections of the power switch according to the layout speci-
fication shown on the label.
☞
When an actuator is switched, the corresponding LED on the power switch light up.
Terminal in
3-way-valve
3 (  )

1
2
Core numbers at the
power switch
1
2
5
