Scope of delivery
Depending on order, comprising:
● Shell kit: ER recessed-mounted housing
● Final assembly set: Fan insert
● Other accessories, e.g. ER-AS for
WC seat ventilation, spacer, wall and cover
frames, expanded rubber fitting etc.
When unpacking the unit, check to
make sure that the delivery is com-
plete. Please contact the dealer if any
accessories are missing or if there
has been any damage in transit.
ER recess-mounted housing (shell)
Recess-mounted housing ER-UP/G
article no. 0093.0995
● Recess-mounted plastic housing with exhaust
socket Ø 75/Ø 80 (no fire protection)
● Plastic shutter
● Plaster protective cover
● Mounting and operating instructions
Recess-mounted housing ER-UPD
article no. 0093.0972
● Recess-mounted plastic housing with metal
exhaust socket Ø 75/Ø 80
● Fire protection shut-off device with air-
stream-operated metal backflow preventer
to prevent fire spreading (K90-18017)
● Plaster protective cover
● Mounting and operating instructions
Recess-mounted housing ER-UPB
article no. ER-UPB:
Recess-mounted housing ER-UPB/..
with second room connection
on right:
article no. ER-UPB/R 0093.0969
on left:
article no. ER-UPB/L
at bottom:
article no. ER-UPB/U 0093.0971
● Recess-mounted plastic housing with fire
protective cover and metal exhaust socket
Ø 75/Ø 80
● Fire protection shut-off device with air-
stream-operated metal backflow preventer
to prevent fire spreading (K90-18017)
● Plaster protective cover
● Mounting and operating instructions
Mounting support UPM 60/100
article no. 0018.0010
● For securing the recessed-mounted housing
0093.0968
0093.0970
Fan inserts (final assembly)
Fan insert ER 60 .. / ER 100 ..
article no. Internet or catalogue.
● Fan inserts with different control circuit
boards, depending on application. Can be
used in all recess-mounted housings ER-
UP/G, ER-UPD and ER-UPB (incl. ER-
UPB/R, ER-UPB/L and ER-UPB/U)
● Internal cover with exhaust air filter
Exhaust air element Centro-M / Centro-E
article no. Internet or catalogue.
● Can be used in all recess-mounted hou-
sings ER-UP/G, ER-UPD and ER-UPB
(incl. ER-UPB/R, ER-UPB/L and ER-UPB/U)
● Internal cover with exhaust air filter
Additional accessories
Second room connection set ER-ZR
article no. 0093.1025
● Comprising protective grille, filter mat adapter,
plastic exhaust socket and regulating plate
Extraction socket ER-AS (Ø 70)
article no. 0093.0928
● For connecting a WC seat ventilation duct
to ER-UP/G and ER-UPD housing
Spacing frame DR 60/100
article no. 0059.0928
● For compensating for projection of max. 2 cm
Wall frame ER-MR, article no. 0018.0024
● For housings that have been plastered too
deeply
Cover frame ER-AR, article no. 0059.0899
● Prevents joints between housing/wall
Expanded rubber fitting ER-MO
article no. 0092.0361
● For acoustic insulation of recess-mounted
housing
Filter mats ZF/ZRF
ZF 60/100: article no. 0093.0680
ZRF: article no. 0093.0923
● ZF 60/100: Replacement air filter for fan
insert ER 60/ER 100
● ZRF: Replacement air filter for second
room connection set ER-ZR
