Operation

Contact clip
For putting the
CLIPLANS SICO 4004
into operation, connect
the two contact clips one
after the other to the rails
of the track section to be
protected.
Contact points
An on-off switch
is not required. To switch on
the device, connect the
contact clips to the rails.
battery compartment
The battery may be replaced
even if the
CLIPLANS SICO 4004
is connected to the rails.
GB-2
Battery low indicator
(red)
This indicator is lit during
the startup if the battery of
the CLIPLANS SICO 4004
is low. Insert then a
charged battery. No
indication will be given if
the battery will weaken
during operation.
lock
Clamping lever
Stop
NOTE:
short distance to protect your eyes! If both contact clips
are connected correctly, the LEDs flash (approx. two
flashes per second) to show that the short circuit
NOTE:
assumed as long as the white signal LEDs are not
Ambient light sensor
The intensity of the
signal LED is adjusted to
the intensity of the
signal LED (white)
Do not look directly into the signal LEDs from
resistance is within its limits.
No safe short circuit of the tracks may be
flashing! Be careful when working in the track!
ambient light.
System state indicator
(yellow)
This indicator will be lit
continuously if the self-test
has failed. In this case,
remove both contact clips
and put the unit into
operation again.
Monitoring unit
Shunt cable
