Operating instructions

The spa control system has automatic functions that operate upon
start-up and normal operation.
Upon power up, the display shows the following information:
I
current version of software: 356 in models with circulation
pump; 556 in models without circulation pump
I
"888" (all LED indicators are on: control of operation of all dis-
play segments and indicator lights).
I
After the initial start-up sequence ends, the actual water tem-
perature is displayed. If water temperature is below 38° C (facto-
ry setting) and the spa is set in skimming/heating mode "F1-F3",
the heater will come on. The heater goes off when water tem-
perature has reached 38° C.
N.B.: it is normal for the heater to turn on after the spa is first filled
because tap water is often very cold.
Setting water temperature
The spa's thermostat provides optimum control of water tem-
perature. The temperature set point (set temperature) can be ad-
justed from 18 °C to 40 °C. To increase the set temperature, press
button (+). To lower it, press ( – ).
N.B.: The first press of either WARMER ( + ) or COOLER ( - ) button
displays the set temperature.
Pump activation
1
2
The control panel JETS 1 button activates jets pump 1. The first
press activates low speed, the second press activates high speed,
and the third press shuts jets pump 1 off. The JETS 2 button ac-
tivates jets pump 2. The first press activates high speed, the sec-
ond press turns jets pump 2 off. When manually activated, ei-
ther pump will automatically turn off after 20 minutes.
Light On/Off Button
Pressing this button activates the waterfall, footwell, accent lights
in unison as follows: high - medium - low - off.
Note: Lights automatically turn off after 2 hours.
Light Mode Button
This button offers 4 light modes for your enjoyment. Press this
button to select your favorite lighting effect as follows:
- High-Speed Color Blend Mode
- Low-Speed Color Blend Mode
- Freeze Color Blend Mode
- Selects or "freezes" your low speed blending color of choice.
- Solid Color Mode
Selects one of 7 solid (high-intensity) colors of choice.
Selecting desired massage action
A
C
B
Each model incorporates a massage selector that allows you to cus-
tomize the massage and performance by diverting water between
various jet systems.
Simply turn massage selector to position A (Combo), B o C, to di-
vert water pressure to various jet groups.
N.B.: The valve is designed to operate in positions A (Combo), B, and C
for optimum performance.
For optimum filtration benefits, leave the valve in position A when spa
is covered. Select position B or C for maximum jet performance during
spa use.
Waterfall Feature
The waterfall is on when jets pump 1 is running. Turn waterfall control
valve counterclockwise to increase waterfall output. Turn control
valve clockwise to decrease or turn off waterfall output.
Jet
The water flow through individual jets in your spa can be ad-
justed or turned off by rotating the outside jet ring. Some jets of-
fer an adjustable center nozzle that allows you to change the
water discharge angle. Simply tilt the center nozzle in these jets
to the desired angle to customize your personal massage. Oth-
er jets offer a spiral action that produces a surging stream of air
and water that provides a vigorous massage.
Note: Always keep at least 6 adjustable jets open at all times to
ensure proper filtration characteristics within the spa. Jets may
not spin with jets pump 1 running in low speed.
Air controls
Certain jet systems have their own "toggle" on/off air control. Each
control introduces air into the water lines that supply specific jet
28
