ADJUSTING OF THE MINIMUM OF
THE TOP BURNERS
In the minimum position the flame must
have a length of about 4 mm and must
remain lit even with a quick turn from the
maximum position to that of minimum.
The flame adjustment is done in the fol-
lowing way:
– Turn on the burner
– Turn the tap to the MINIMUM position
– Take off the knob
– With a thin screwdriver pass by the
hole of microswitch and turn the screw
F until adjustment is correct (fig. 9.5).
Normally for G30/G31, tighten up the
regulation screw.
Fig. 9.5
F
LUBRICATION OF THE GAS TAPS
The operations must be executed by a
qualified technician.
IMPORTANT
All intervention regarding installa-
tion maintenance and conversion
of the appliance must be fulfilled
with original factory parts.
The manufacturer declines any
liability resulting from the non-
compliance of this obligation.
51
