INSTALLATION
LOCATION
The appliance must be kept no less than 50 mm away from any side wall which exceed
the height of the hob surface (fig. 8.2a - 8.2b).
The appliance must be housed in heat resistant units.
The walls of the units must be capable of resisting temperatures of 75 °C above
room temperature.
Do not install the appliance near inflammable materials (eg. curtains).
If the cooker is located on a pedestal it is necessary to provide safety measures to pre-
vent falling out.
Before installing the cooker level the appliance by screwing or unscrewing the six
adjustable feet fitted below.
WARNING!
For safety reasons unscrew
the feet (from screwed posi-
tion) to the maximum extent of
5 mm (fig. 8.1).
44
Fig. 8.1
Gas connection
made using rubber
hose which must be
visible and easily
inspected or using
rigid or flexible metal
pipe.
Fig. 8.2a
Class 1
