INSIDE OF OVEN
This must be cleaned regularly.
Remove and refit the side runner frames
as described on the next chapter.
With the oven warm, wipe the inside
walls with a cloth soaked in very hot
soapy water or another suitable product.
Side runner frames, tray and rack can
be removed and washed.
DRAWER
The drawer (fig. 7.9) comes out like a
normal drawer.
Do not store flammable material in
the oven or in the drawer.
REMOVING THE BOTTOM LEFT OVEN
DOOR
The oven door can easily be removed as
follows:
– Open the door.
– Unscrew the 4 screws of the bottom
– Hold the door and unscrew the 3
– Remove the door following the arrow C
– Rest the door on a soft surface.
– To replace the door, repeat the above
Fig. 7.9
hinge (fig. 7.11)
screws of the upper hinge (fig. 7.10).
(fig. 7.10 - 7.11)
steps in reverse order.
c
Fig. 7.10
c
Fig. 7.11
