A
Metall-Rolloträger
Metal bracket – Support métallique
MONTAGEHINWEISE
• Stoffablauf standardmäßig fensterseitig
• Träger waagerecht anbringen
ASSEMBLY INSTRUCTIONS
•
Fabric passes on the window side
•
Fix the brackets horizontally
INDICATIONS DE MONTAGE
•
Déroulement du tissu sur la côte de fenêtre en série
•
Fixer le support à l'horizontale
WAND- / DECKENMONTAGE
WALL / NICHE FIXATION
FIXATION MURALE / EN EMBRASURE
min 35
Bestellbreite
ordered with
largeur comandée
Clip für Wand- oder Deckemontage
Clip for the wall or ceiling fixation
Clip pour la fixation murale ou plafond
Position der Clips festlegen und
anzeichnen
Fix and mark the positions of the clips.
Fixer et marquer les positions des clips.
Breite
Clips
width - largeur
Clips
300 - 1000 mm
2
1001 - 1900 mm
3
1991 - 2800 mm
4
1
Clips anschrauben
Screw the clips
Visser les clips
Trägerprofil einsetzen...
Put the bracket profile in...
Mettre le profil de montage en place...
... und einclipsen
. . . and let it clip in
. . . et laisser l'enclecher
2
