WATER PUMP (REGULAR ROTATION MODELS)

REMOVING/INSTALLING THE WATER PUMP

18 Nm (1.8 m • kgf, 13 ft • Ib)
8 × 45 mm
572 572
A
10
A
Order
Lower unit
1 Bolt
2 Impeller housing
3 Impeller housing cup
4 O-ring
5 O-ring
6 Grommet
7 Spacer
8 Collar
WATER PUMP (REGULAR ROTATION MODELS)
1
6
7
2
4
3
5
8
9
11
12
14
15
16
Job/Part Q'ty
Refer to "LOWER UNIT (REGULAR
ROTATION MODELS)" on page 6-1.
4
1
1
1
1
1
1
1
