Welding mask slips
• Head band not adjusted properly
(must be lowered).
If faults cannot be corrected, the shade cartridge must
not be re-used! Please contact your dealer.
Technical data
Type Select
Automatic 4/10-11 and 4/11-12
Manually adjustable with slide switch:
10-11 or 11-12
Type 10/11 MONO
Automatic 4/10
Automatic 4/11
Switching time: light to dark
0.1 ms at + 55°C / 131°F
Switching time: dark to light
0,2-0,3 s
UV/IR protection
max. UV/IR protection with every cartridge state
Energy source
Solar cells, no battery change required
Operating temperature
- 10°C to + 70°C / 14°F to 158°F
Total weight
470 g / 16,58 oz
Size of cartridge
90 x 110 x 6.6 mm /
3,54 x 4,33 x 0,26"
Viewing Area
98 x 38 mm / 3,86 x 1,50"
Water-resistant
Waterproof in accordance with IP 67
(Test duration 30 minutes; depth 1 m / 3,28')
Mask material
High-impact plastic, stability of shape up to 219°C/426°F
All data are subject to change without
prior notice
G
Replacing the front cover lens
Hold the front lens frame at bottom edge and pull away
upwards. Insert the front cover lens into the frame and clip
the front lens frame back into place -first the top and then
bottom; press
firmly into place.
Only use original ESAB front cover
lenses!
Warning
!
and set proper filter shade. See ANSI/AWS Z49.1 for guide. Available from:
American Welding Soociety, Miami, FL 33135
H
Replacing inside cover lens
Use the finger nails to lift and pull out the lens.
I
Replacing the magnifiers
Use the finger nails to lift and pull out the
magnifying lens.
J
Eccentric knob
For setting the inclination of the mask.
K
Undo the locking knobs and set the eye
distance. Set both side equally and do not
tilt; tighten the locking knobs.
L
Adjusting the head band
Set the upper adjustable band to a tem-
porary position (as low as possible).
M
Press in the ratchet button (star knob)
and turn until the head band sits firmly,
but not too tightly.
N
Sweat band
Can be replaced and washed
O (Select)
Shade range adjustment
Protection level
10-11 automatic
11-12 automatic
10-11 perceived as too light
11-12 perceived as too dark
If the switch is defective
P (10/11 MONO)
Shade adjustment
Protection level
10 automatic
11 automatic
10 perceived as too light
11 perceived as too dark
If the switch is defective
Q
To remove the sensor bar pitch the bar
downwards and pull it out.
ARC RAYS can burn eyes and skin. Wear safety glasses
Position
10-11
11-12
11-12
10-11
11
Position
10
11
11
10
10
