Table of Contents
Specifications on page 3
General information on page 3
Installation on page 7
Startup on page 13

Specifications

Specifications are subject to change without notice.
Specification Details
Dimensions (W x D x 17.15 x 11.43 x 31.75 cm (6.75 x 4.5 x 12.5 in.)
H)
Enclosure 304 stainless steel
Light source Long Life Laser
Weight 4.6 kg (10.2 lb)
Pollution degree 2
Installation category DC models: I
AC models: II
Protection class DC models: III
AC models: II
Power requirements DC models: 24 VDC ± 10%, 60 W maximum
AC models: 100-240 VAC, 50-60 Hz, 0.4 A maximum
Operating temperature 5 to 40 °C (40 to 104 °F); best performance: 10 to
32 °C (50 to 90 °F)
Storage temperature -40 to 70 °C (-40 to 158 °F)
Operation on page 13
Maintenance on page 20
Troubleshooting on page 22
Replacement parts and accessories
on page 22
™ diode, Class 3B laser
Specification Details
Humidity Operating: 80% up to 31 °C (88 °F) decreasing linearly
to 50% relative humidity at 40 °C (104 °F)
Storage: 5 to 98% relative humidity, non-condensing
Altitude 2000 m (6562 ft) maximum
Fitting sizes Model 6015P: Barb fitting for 1/4-in. ID inlet tubing, 3/8-
in. ID exhaust tubing; optional 3/8-in. ID inlet fitting
Output signal options Pulse, analog 4-20 mA, serial RS232 with Modbus
RTU or FXB communication protocol (no networking),
serial RS485 with Modbus RTU or FXB communication
protocol, Ethernet with ModbusTCP protocol
Data storage 1000 samples (records), oldest records are written over
when the buffer is full
Sample flow rate Model 6015P: 1.0 cfm (28.3 L/min) ± 5%
Range Model 6015P: 0.5 μm to 10.0 μm at 1.0 cfm
(28.3 L/min)
Sensitivity Model 6015P: 0.5 μm at 1.0 cfm (28.3 L/min)
Counting efficiency Model 6015P: 50% ± 20% at 0.5 μm and 100% ± 10%
for sizes at least 1.5 times, or larger than the smallest
channel size
Coincidence loss Model 6015P: 10% at 20,000,000 particles/m
(566,000 particles/ft
False count rate One or less in 5 minutes
Pump type Air vacuum, rated for continuous use
Certifications Certified to UL and CSA by ETL, CE
1
Fully complies to JIS and ISO 21501-4.

General information

In no event will the manufacturer be liable for direct, indirect, special,
incidental or consequential damages resulting from any defect or
omission in this manual. The manufacturer reserves the right to make
1
.
