ENGLISH
IMPORTANT: The instruction manual you are holding includes essential information on the safety measures to be implemented for
installation and start-up. Therefore, the installer as well as the user must read the instructions before beginning installation and start-up.
Keep this manual for future reference.
To achieve optimum performance of the Floodlamp follow the instructions provided below:
1. VERIFY THE CONTENTS OF THE PACKING:
The following accessories are included inside the box:
Housing body
Floodlamp unit
2 watertight joints
Clamp
Floodlamp unit
Bag of screws: 2 DIN 7981 A2 4,8x16 screws

2. GENERAL CHARACTERISTICS:

This floodlamp has been designed to be used fully submerged underwater in fresh water swimming pools. It is a
Class III electric apparatus with very low safety voltage (12V with alternating current).
The floodlamp compiles with IPX8 degree of protection (resistance to penetration of dust, solid bodies and
humidity) at a nominal immersion depth of 2 m.
This floodlamp compiles with international safety standards for lights, especially the EN 60598-2-18 standard.
LIGHTS PART 2: SPECIFIC REQUIREMENTS SECTION 18 LIGHTS FOR SWIMMING POOLS AND SIMILAR
APPLICATIONS.
The manufacturer is not responsible in any circumstances for assembly, installation or start-up of any electric
components which have been inserted or handied at locations other than its own premises.
3. INSTALLATION:

Never install in vertical positlon with the lamp facing downwards,

In order to clearly light a pool it is recommended lo install a 24W floodlamp every 20 m² of water surface.

In order to prevent glare, the floodlamps should be installed so that they face away from the residence or usual
view of the swimming pool.

In the event that lighting is used in training or competition pools, the floodlamps should be installed on the sides
to prevent glare on the swimmers.

To avoid the need to empty the pool to change the lamp, we recommend that the floodlamp be installed in areas
which are accessible from the upper edge of the pool.
Prior to installation verify that the gland seal (no. 10) has been fully tightened.
The floodlamp should be placed on the wall of the pool at approximately 400-700 mm from the water surface (Fig.
1).
To install a fioodlamp in prefabricated swimming pool make a circular hole with a diameter of 240 mm (Fig. 2).
Install the housing (no. 15) and one of the adhesive joints (no. 14) on the outer side of the pool. Install the other
adhesive joint on the inner side and use two screws DIN 7981 4,8x16 (no. 13) to secure the three components.
(Fig. 3). Make sure that the cable outlet of the housing remains on the upper part.
To install the clamp (no. 11) on the inner side of the swimming pool, make sure that the heads of the screws DIN
7981 4,8x16, which have been installed previously (no. 13), coincide with the área reserved for them on the back
part of the clamp.
Secure the clamp (no. 11) to the pool wall using 16 screws, DIN 7982 5,5 x 25 (no. 12) (Fig. 4).
4. ASSEMBLY:
After installation of the housing and the clamp, assemble the floodlamp.
To connect the floodlamp to the electric power supply insert the cable through the gland seal nut (no. 10). Tighten
the gland seal nut until you can verify that the cable will not yield when you pull on it with your hand.
16 DIN 7982 5,5x25 screws
2
