• Secure the set screw (16b) again.
• Move the machine head (4) to the top position.
• Fix the rotary table (14) in the 0° position.
• Loosen the set screw (22) and use the handle (1)
to angle the machine head (4) to the left, until the
pointer (19) indicates the desired angle measure­
ment on the scale (18).
• Re-tighten the fixing screw (22).
• Cut as described in section 8.3.
8.7 Mitre cut 0°- 45° and turntable 0°- 45°
(Fig. 2/4/13)
The crosscut saw can be used to make mitre cuts to
the left of 0°­ 45° in relation to the work face and, at
the same time, 0° ­ 45° to the left or 0° ­ 45° to the
right in relation to the stop rail (double mitre cut).
Important. To make miter cuts (inclined saw head),
the adjustable stop rail (16a) must be fixed at the outer
position.
• Open the set screw (16b) for the adjustable stop rail
(16a) and push the adjustable stop rail outwards.
• The adjustable stop rail (16a) must be fixed far
enough in front of the innermost position that the
distance between the stop rail (16a) and the saw
blade (6) amounts to a maximum of 8 mm.
• Before making a cut, check that the stop rail (16a)
and the saw blade (6) cannot collide.
• Secure the set screw (16b) again.
• Move the machine head (4) to its upper position.
• Release the rotary table (14) by loosening the set
screw (26).
• Using the handle (11), set the rotary table (14) to the
desired angle (refer also to point 8.4 in this regard).
• Re­tighten the set screw (26) in order to secure the
rotary table.
• Undo the locking screw (22) and use the handle (1)
to tilt the machine head (4) to the left until it coin­
cides with the required angle value (in this connec­
tion see also section 8.6).
• Re-tighten the fixing screw (22).
• Cut as described under section 8.3.
8.8 Limiting the cutting depth (Fig. 3/14)
• The cutting depth can be infinitely adjusted using the
screw (24). To do this loosen the knurled nut on the
screw (24). Move the stop for the cutting depth limi­
tre (25) to the outside. Turn the screw (24) in or out
to set the required cutting depth. Then re­tighten the
knurled nut on the screw (24).
• Check the setting by completing a test cut.
8.9 Sawdust bag (Fig. 1)
The saw is equipped with a debris bag (17) for saw­
dust and chips.
Squeeze together the metal ring on the dust bag and
attach it to the outlet opening in the motor area.
The debris bag (17) can be emptied by means of a zip­
per at the bottom.
28 GB
8.10 Changing the saw blade (Fig. 15/16/17/18)
Remove the power plug!
Important.
Wear safety gloves when changing the saw blade.
Risk of injury!
• Swing up the machine head (5).
• Undo the screw (e) on the guide bar (37), so that it can
move freely and be pivoted downwards.
• Press the release lever (3). Swing up the saw blade
guard (6) to the point where the recess in the saw
blade guard (6) is above the flange bolt (31).
• Press the saw shaft lock (4) with one hand. With the
other hand insert the allen key (d) in the flange bolt (31).
• Hold the Allen key (d) and slowly close the saw blade
guard until it touches the Allen key.
• Firmly press the saw shaft lock (4) and slowly rotate the
flange bolt (31) in clockwise direction. The saw shaft lock
(4) engages after no more than one rotation.
• Now, using a little more force, slacken the flange bolt
(31) in the clockwise direction.
• Turn the flange screw (31) right out and remove the
external flange (32).
• Take the blade (7) off the inner flange (38) and pull
out downwards.
• Carefully clean the flange screw (31), outer flange (32)
and inner flange (38).
• Fit and fasten the new saw blade (7) in reverse order.
• Important! The cutting angle of the teeth, in other
words the direction of rotation of the saw blade (7)
must coincide with the direction of the arrow on the
housing.
• Move the guide bar (37) into position and tighten the
screw (e) again.
• Before continuing your work make sure that all safety
devices are in good working condition.
• Important! Every time that you change the saw blade
(7), check to see that it spins freely in the table insert
(11) in both perpendicular and 45° angle settings.
• Important! The work to change and align the saw
blade (7) must be carried out correctly.
8.11 Using the laser (Fig. 3/19/20)
• To switch on: Move the ON/OFF switch of the laser
(34) to the "1" position. A laser line is projected onto
the material you wish to process, providing an exact
guide for the cut.
• To switch off: Move the ON/OFF switch of the laser
(34) to the "0" position.
• Replacing the battery: Switch off the laser (33).
Remove the battery compartment cover (36). Re­
move the batteries and replace with new batteries
(2 x 1.5 Volt Type LR 03 Micro, AAA) Check that
the battery terminals are positioned correctly when
inserting new batteries. Close the battery compart­
ment (35) again.
