Hach HQ1110 Manuel D'utilisation De Base page 4

Meter model Probe
connectors
HQ1110
HQ1130
HQ1140
HQ2100
HQ2200
HQ4100
HQ4200
HQ4300
Section 3 Specifications
Specifications are subject to change without notice.
Specification
Dimensions (L x W x H)
Weight
Enclosure rating
Power requirements (internal)
Power requirements
(external)
Meter protection class
Operating temperature
Charging temperature
Operating humidity
Storage temperature
Probe connector
Micro-USB connector
Data log (internal)
2
pH/mV/ORP probes include temperature
3
LDO/LBOD probes include temperature
4
Conductivity probes include salinity, TDS (total dissolved solids), resistivity, temperature
5
Ion-selective probes such as ammonia, nitrate, chloride, fluoride, sodium
4 English
Table 1 HQ Series meter models
pH/mV/ORP
probes
1
✔
1
1
1
✔
2
✔
1
✔
2 ✔
3
✔
Details
22 x 9.7 x 6.3 cm (8.7 x 3.8 x 2.5 in.)
HQ1110, HQ1130, HQ1140 and HQ2100: 519 g (18.3 oz); HQ2200: 541 g
(19.1 oz); HQ4100: 530 g (18.7 oz); HQ4200: 550 g (19.4 oz); HQ4300: 570 g
(20.1 oz)
IP67 with battery compartment installed
Rechargeable lithium-ion battery 18650 (18-mm diameter x 65-mm length,
cylindrical), 3.7 VDC, 3400 mAh; Battery Life: > 1 week with typical use
(10 readings/day, 5 days/week in Continuous or Push to read mode, or >
24 hours in Interval mode with 5 minute intervals and shutdown timer ≤
15 minutes)
Class II, USB power adapter: 100–240 VAC, 50/60 Hz input; 5 VDC at 2 A USB
power adapter output
IEC Class III (SELV (Separated/Safety Extra-Low Voltage) powered); USB power
adapter is IEC Class II (double-insulated)
0 to 60 °C (32 to 140 °F)
10 to 40 °C (50 to 104 °F)
90% (non-condensing)
–20 to 60 °C (–4 to 140 °F) maximum 90% relative humidity (non-condensing)
5-pin M12 connector for Intellical probes
The micro-USB connector enables USB cable and USB power adapter
connectivity.
HQ1000 Series: 5000 data points; HQ2000 Series: 10,000 data points;
HQ4000 Series: 100,000 data points
2 3
LDO/LBOD
probes
✔
✔
✔
✔
✔
✔
4 5
Conductivity ISE
probes
✔
✔
✔
✔
✔
✔
probes
✔
✔
✔
