1 Operating Elements
and Connections

1.1 Multi-frequency receiver

1 Receiving antennas A and B
2 Button SELECT for channel adjustment
To use the automatic search for a free reception
channel, press the button briefly.
To use the manual adjustment, keep the button
SELECT pressed until the units digit on the dis-
play starts flashing. Press the button briefly to
adjust the units digit. Keep the button pressed
again until the tens digit on the display starts
flashing. Press the button briefly to adjust the
tens digit. (The frequencies corresponding to
the channels can be found in the tables on
page 40.)
3 Display for channel indication
4 LED AF (audio frequency): lighting up when the
received audio signal exceeds a defined level
5 Reception LEDs RF (radio frequency) A and B:
to indicate which of the two receiving parts of
the unit receives the more powerful radio signal
6 IR window for the IR signals to adjust the chan-
nel of the wireless microphone or of the pocket
transmitter
7 Button ACT for sending the IR signals to adjust
the channel of the wireless microphone or of the

pocket transmitter

8 Power supply jack to connect the power supply
unit provided
9 POWER switch
10 XLR audio output for connection to a micro-
phone input
11 Audio output (6.3 mm jack) for connection to a
line input
12 VOLUME control for the audio signal of the out-
puts (10, 11)
13 SQUELCH control to adjust the threshold for
interference suppression
10

1.2 Wireless microphone

for TXS-611SET and TXS-616SET only
14 Display with channel indication and battery sta-
tus indication
15 Sensor for the IR signals to adjust the channel
16 On / off switch
lower position: off
mid-position: mute
upper position: on
17 Battery compartment
18 Switch LOCK to lock the microphone
position OFF lock deactivated
position ON lock activated
19 Switch POWER for the transmission power
position LO low transmission power
position HI high transmission power
1.3 Pocket transmitter
for TXS-631SET and TXS-636SET only
20 Transmitting antenna
21 On / off switch
OFF
STBY = mute
ON
22 Display with channel indication and battery sta-
tus indication
23 Sensor for the IR signals to adjust the channel
24 Cover of battery compartment
25 Jack to connect the tie clip microphone
26 Belt clip
27 GAIN control the microphone signal
28 Battery compartment
