Front Panel; Rear Panel - Denon DJ SC6000 PRIME Guide D'utilisation

34. Auto Loop/Loop Move: Turn this knob to set the size of an automatic loop. The value will be shown in the
touchscreen and platter display.
Press this knob to activate or deactivate an automatic loop at the current location of the track.
Tip: You can assign auto loops to pads in Manual Loop Mode. See
information.
Press and hold Shift and turn this knob to shift the active loop to the left or right.
35. Beat Jump: Press either of these buttons to skip backward or forward through the track. Use the Auto Loop knob
to determine the beat jump size.
Press and hold Shift and then press one of these buttons to search backward or forward through the track.

Front Panel

1. Front USB Port: Connect a standard USB drive to this
USB port. When you select that USB drive as a source
(press the Source button), you can use the display to
select and load tracks from your USB drive. There are
also two similar USB ports on the rear panel. You can
use the included USB extension cable to accommodate
larger or smaller USB thumb drives.
2. SD Card Slot: Insert a standard SD card to this slot.
When you select that SD card as a source (press the
Source button), you can use the display to select and
load tracks from your SD card.

Rear Panel

1. Power Input: Use the included locking power cable to
connect this input to a power outlet. To remove the
power cable, push down on the yellow tab and then pull
the cable out of the input. You can also use a standard
IEC power cable in place of the included locking power
cable.
SC6000 PRIME has a protection circuit to safely eject all
media after an unexpected power loss to protect your data
from corruption. Reconnect your power source to return to
normal operation.
2. Power Button: Press this button to power SC6000 PRIME on or off. Power on SC6000 PRIME only after you have
connected all of your input devices and before you power on your amplifiers and loudspeakers. Power off your amplifiers
and loudspeakers before powering off SC6000 PRIME.
Press and hold this button for 10 seconds to reset SC6000 PRIME.
3. Link Port: Use the included networking cable to connect this port to another SC6000 PRIME or to your Denon DJ
mixer. Each networked SC6000 PRIME can share track databases, timing and BPM information, and other track
data over this connection.
4. USB B Port: Use a standard USB cable (included) to connect this USB port to an available USB port on your
computer. This connection sends and receives MIDI messages to and from the computer.
5. Rear USB Ports 2/3: Connect standard USB drives to these USB ports. When you select one of those USB drives
as a source (press the Source button), you can use the display to select and load tracks from your USB drives.
There is also a similar USB port on the front panel.
6. Layer A/B Outputs: Use standard RCA cables to connect these outputs to your DJ mixer. The Layer A Line Outputs
send out the audio signal from Layer A. The Layer B Line Outputs send out the audio signal from Layer B.
7. Digital Outputs A/B: Use standard digital coaxial cables to connect these 24-bit/96 KHz outputs to devices and
mixers such as the Denon DJ X1850 PRIME.
8. Remote Input: Use a standard remote start cable to connect this input to the remote-start output of your mixer (if
available). While connected to a remote-start-compatible mixer, moving the crossfader toward the side that
corresponds to this SC6000 PRIME (or raising the channel fader for its channel) will automatically start the track on
the currently selected layer.
®
9. Kensington Lock Slot: Use this slot to secure SC6000 PRIME to a table or other surface.
Operation > Performing > Pad Modes
2
1
8
3
5 4
6 7
for more
