9 Maintenance and cleaning
NOTICE
• Ensure that the sealing surfaces between the device cover (1) and the pressure flange (5) are clean and undamaged.
Replace the rubber seal if necessary.
 Replace the rubber seal if necessary. 9.4 Replace rubber seal on page EN-16
CAUTION

Material damage

Using the incorrect release agent can damage the TSi injection unit.
• Only operate the TSi injection unit with original ABICOR BINZEL release agent.
• Only operate the TSi injection unit with original collection receptacle.
4 Remount all parts in the reverse order.
9.3 Clean the injection nozzle
 Fig. 10 Maintenance and cleaning on page EN-14
1 Unscrew the device cover (1) using the bayonet closure (2). Remove pressure flange (5) and collection receptacle (4).
NOTICE
• Use an AF 14 spanner or the collection receptacle (4) to unscrew the injection nozzle (3).
WARNING
Risk of injury
Serious injuries may be caused by parts swirling around.
• When cleaning with compressed air, wear suitable protective clothing, in particular safety goggles.
2 Unscrew the injection nozzle (3). Remove dirt and air-blast from both sides with compressed air.
3 Screw in the injection nozzle (3) again by hand and remount all parts in the reverse order.
EN - 16
TSi injection unit
BAL.0468.0 • 2021-10-28
