4.8 - MENU OF ADVANCED FUNCTIONS

To access the advanced features menu, press and hold the MENU button for longer than 5 seconds.
Use the UP and DOWN buttons to scroll through the available features.
While displaying a function, the control unit will alternate the display of the item to the value set in it.
To change the value of the parameter you are viewing proceed as follows:
• Press and hold the menu key for at least 3 seconds, the currently set value flashes.
• Use the UP and DOWN keys to select the desired value.
• Confirm the value by holding down the MENU key for at least 3 seconds.
To exit quickly press the MENU button.
Mode of intervention of the impact sensor
• Adjust this parameter according to current regulations.
Determines the behavior of the control unit when the impact sensor is activated during movement.
If the impact is interpreted as an obstacle, the control unit stops the automation and performs a brief reversal.
If the impact is interpreted as a end position, the control unit stops the automation and considers that position as GATE OPEN or
GATE CLOSED depending on the direction of movement.
Value 0: Always disabled.
Value 1: Standard mode: Depending on the position, it interprets intervention as an impact against an obstacle (at normal speed)
or as reaching the limit switch position (in deceleration).
Value 2: Obstacle mode: Always interpret the intervention as impact against an obstacle.
Value 3: End-switch mode: Always interprets the intervention as reaching the end position.
PARAMETER
SnM
Intervention time of the impact sensor
It determines how long the impact sensor takes after reaching the obstacle (blocked motor).
PARAMETER
Sit
Impact sensor disabling time at motor start
Determines how long the impact sensor is disabled at the start of handling.
PARAMETER
Sdt
6-1622521M - rev. 0 - 25/02/2025
PARAMETER LIST
VALUES
OFF = disabled
1 = Standard mode
2 = Obstacle mode
3 = End-switch mode
VALUES
from 1 to 10 multiplied by 100 ms
VALUES
from 0 to 30 multiplied by 100 ms
NOTE
Translated from the original language - English - 29
DEFAULT
2 = Obstacle mode
DEFAULT
2 = 200 ms
DEFAULT
15 = 1500 ms
