2. Package Contents and Technical Specifications

Control Panel

1
2
Charging Dock
1
2
3
4
1. Infrared Signal Generators
2. Charging Dock Pins for Robot
3. Automatic Emptying Dust Intake
Dust Bin
1
2
3
4
5
3 4 5
5
6
4. Anti-Slip Strips
5. Charging Dock Pins for
Handheld Vacuum Cleaner
1. AUTO Mode Button
2. Wi-Fi Indicator
3. Scheduled Cleaning Indicator
4. Spot Mode Indicator
5. Return to Charger Mode Indicator
6. Automatic Emptying
Dust Transfer Channel
7. Power Adapter
1. Dust Bin Handle
2. Filter Net
3. High Efficiency Filter
4. Dust Bin Cover
5. Dust Bin Lock
7
7
