System Map: Right & Rear Views
4
1 2 3
CD Emergency Eject
If you need to manually eject a CD/DVD
(e.g. due to an unexpected power inter-
ruption) you may push the end of a
straightened paper clip into the emer-
gency eject hole. Do not use a sharp-
ened pencil or similar object that may
break and become lodged in the hole.
Media Warning
Don't try to remove a floppy disk/CD/
DVD while the system is accessing it.
This may cause the system to "crash".
Right
5
6
Rear
9
Changing DVD Regional Codes
Go to the Control Panel and double-click Device
Manager (Hardware and Sound), then click the +
next to DVD/CD-ROM drives. Double-click on the
DVD-ROM device to bring up the Properties dialog
box, and select the DVD Region (tab) to bring up the
control panel to allow you to adjust the regional
code.
DVD region detection is device dependent, not OS-
dependent. You can select your module's region
code 5 times. The fifth selection is permanent. This
cannot be altered even if you change your operating
system or you use the module in another computer.
Concise User's Guide
Right & Rear Views
1.
2.
3.
7 8
4.
5.
6.
7.
8.
9.
System Map: Right & Rear Views - 15
Figure 6
S/PDIF-Out Jack
Microphone-In Jack
Headphone-Out Jack
USB 2.0 Port
Optical Device Drive
Bay
Emergency Eject Hole
RJ-11 Phone Jack
Security Lock Slot
Battery
