Dimensions
Installation
The information contained herein is based on sources that we believe to be reliable
, but is not guaranteed by us, may be incomplete and/or may change without notice.
Need technical support? 1(888) 651-2534
*Monday to Friday from 8h30 to 16h30 EST
A Floor to ceiling height
Floor to counter top height
B
(standard)
Recommended height between
C cooking surface and bottom of
the hood
Hood height (including
D
transition height (4'')
E Cabinet height
*
variable
36''
28'' to 30''
16''
N/A
25
AVP286PPS/AVP3410PPS
Duct transition
AVP286PPS
top 6'' Round
Haut 6'' Rond
AVP3410PPS
top 10'' round
