Mounting precautions
•
When moving the monitor, be sure to hold its sides or bottom. Do not hold the LCD panel or
buttons. This may cause product damage, failure, or injury.
•
To attach a VESA-compliant mounting bracket, use M4 screws that are 6 mm to 10 mm longer than
the thickness of the mounting bracket.
6 - 10 mm
•
Be sure to use a wall-mount bracket designed or designated for mounting the monitor.
•
This monitor and bracket must be installed on a wall which can endure at least 4 times or more the
weight of the monitor.
Install by the most suitable method for the material and the structure.
•
Do not use an impact driver.
•
Do not use any screw holes other than those for mounting brackets, located on the rear of the
monitor, for installation.
100 mm
100 mm
Screw holes for mounting brackets
•
When installing, check the tilt angle in the Product Specifications.
•
After mounting, please carefully ensure the monitor is secure, and not able to come loose from the
wall or mount.
Screws (M4)
Mounting bracket
Monitor mounting
English-9
9
≦ 5°
EN
> 5°
