3.3
SensoUpload
When SensoUpload is called up by clicking on the respective tab, the user password is requested as the sensor's run
mode must be interrupted to upload data.
With this module, configurations defined in SensoConfig and stored as files on the Vision Viewer CE in the directory:
.../Sensor/Sensor_Upload relative to SensorViewerCE.exe (type. sca) can be loaded on to the sensor.
Each configuration stored under this path appears on the user interface as an individual button. Activating the button,
triggers the uploading of the respective configuration on to the sensor. The sensor is temporarily interrupted for this
purpose and is immediately brought back into run mode after upload, using the new settings.
Technical data
Display
Interfaces
Power supply
Operating system
Dimensions LxWxH
Weight
26
TFT 5.6 inch, VGA 640x480 Pixel, Touch screen, LED backlight, 280/350 cd/m²
Ethernet 10/100 Mbps1x COM1- Port2x USB 2.0 Full Speed Host
12V to 24 VDC
Windows® CE5.0
138x117x55 mm
390g
operating instructions
Fig. 11
155-01110
Vision Viewer CE FA 45 GB - 068-14298 - 23.03.2010-00
