If the battery pack still fails to charge, send
•
the charger and charging adapter
•
and the battery pack
to our customer service center.
To ensure that items are properly packaged
and delivered when you send them to us,
please contact our customer service or the
point of sale at which the equipment was
purchased.
When shipping or disposing of batteries and
cordless tools, always ensure that they are
packed individually in plastic bags to prevent
short circuits and fi res.
To ensure that the battery pack provides long ser-
vice, you should take care to recharge it promptly.
You must recharge the battery pack when you
notice that the performance of the device drops.
Never allow the battery pack to become fully di-
scharged. This will cause it to develop a defect.
6.2 Battery capacity indicator (Fig. 1c/Item 9)
Press the battery capacity indicator switch (a).
The battery capacity indicator (9) shows the char-
ge status of the battery using 3 LEDs.
All 3 LEDs are lit:
The battery is fully charged.
2 or 1 LED(s) are lit:
The battery has an adequate remaining charge.
1 LED blinks:
The battery is empty, recharge the battery.
All LEDs blink:
The battery pack has undergone exhaustive di-
scharge and is defective. Do not use or charge a
defective battery pack.
6.3 Switching on (Fig. 7)
To switch on, push the On/Off switch (2) forwards
and press it down. To switch off the angle grinder,
press down the On/Off switch (2) at the back. The
On/Off switch (2) will jump back into its starting
position.
Important!
The equipment will switch to "Standby Mode" af-
ter 10 minutes of non-use.
To reactivate: Switch on the equipment twice or
press the battery capacity indicator.
"Standby Mode" protects the battery.
Anl_TC_WS_18_Li_SPK7.indb 20
Anl_TC_WS_18_Li_SPK7.indb 20
GB
Important!
Following a stoppage (due to overloading), the
cordless equipment will start up again automati-
cally.
Wait until the machine has reached its top
speed. You can then position the angle grin-
der on the workpiece and machine it.
6.4 Changing the grinding wheels (Fig. 8 / 9)
Use the face spanner (5) supplied to change the
grinding wheels. The face spanner (5) is stored in
the additional handle (3). Pull the face spanner (5)
out of the additional handle (3) when you need it.
Danger! For safety reasons, the angle grinder
must not be operated with the face spanner (5)
inserted in it.
Warning!
•
Simple wheel change by spindle lock:
•
Press the spindle lock and allow the grinding
wheel to latch in place.
•
Open the flange nut with the face spanner.
(Fig. 9)
•
Change the grinding or cutting wheel and
tighten the flange nut with the face spanner.
Notice!
Only ever press the spindle lock when the
motor and grinding spindle are at a stand-
still! You must keep the spindle lock pressed
while you change the wheel!
For grinding or cutting wheels up to approx. 3 mm
thick, screw on the fl ange nut with the fl at side
facing the grinding or cutting wheel.
6.5 Flange arrangements when using grin-
ding wheels and cutting wheels (Fig. 10-
13)
•
Flange arrangement when using a de-
pressed-centre or straight grinding wheel
(Fig. 11)
a) Clamping flange
b) Flange nut
•
Flange arrangement when using a de-
pressed-centre cutting wheel (Fig. 12)
a) Clamping flange
b) Flange nut
•
Flange arrangement when using a straight
cutting wheel (Fig. 13)
a) Clamping flange
b) Flange nut
