2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
5. Before starting the equipment
Warning!
Always remove the battery pack before making
adjustments to the equipment.
5.1 Fitting the additional handle (Fig. 2)
•
The angle grinder must not be used without
the additional handle (3).
•
The additional handle can be secured in any
of three positions (A, B).
Tool side
Left (position A / as
shown)
Right (position B)
5.2 Replacing and adjusting the guard (Fig. 3)
Replacing:
•
Remove the flange nut (b) and the clamping
flange underneath.
•
Open the clamp lever (a) on the guard (4).
•
Turn the guard (4) through 180° in clockwise
direction so that the guard points upwards.
•
Remove the guard (4).
To mount, proceed in the reverse order.
Adjusting:
•
Adjust the guard (4) to protect your hands
so that the material being ground is directed
away from your body.
•
The position of the guard (4) can be adjusted
to any specific working conditions. Undo the
clamp handle (a) and turn the cover (4) into
the required position.
•
Ensure that the guard (4) correctly covers the
gear wheel casing.
•
Secure the clamp handle (a) again.
•
Ensure that the guard (4) is secure.
Take care that the safety device is secure.
Never use the angle grinder without the
Anl_TC_WS_18_Li_SPK7.indb 19
Anl_TC_WS_18_Li_SPK7.indb 19
GB
Suitable for
Right-handed users
Left-handed users
- 19 -
guard.
5.3 Fitting/removing the cutting wheel guard
(Fig. 4-6 / Item 10)
•
The angle grinder is equipped with a remo-
vable cutting wheel guard (10).
•
The guard (4) does not need to be replaced
in order for you to fit the cutting wheel guard.
•
Beginning from the end with the lug (Fig. 4/
Item f), push the removable cutting wheel gu-
ard (10) onto the guard.
•
Make sure when doing so that the guard (4)
lies between the guide ribs (g) of the remo-
vable cutting wheel guard (Fig. 4).
•
Then push the removable cutting wheel guard
counter-clockwise onto the guard until you
hear this guard latch in place (Fig. 5a-5c).
•
To take off the removable cutting wheel guard
(10) again, press the lug (f) slightly away from
the guard (4) as shown in Fig. 6 until you can
rotate the removable cutting wheel guard
(10). Now turn the cutting wheel guard clock-
wise and off the guard (4).
5.4 Test run for new grinding Wheels
Allow the right-angle grinder to run in idle for at
least 1 minute with the grinding or cutting wheel
fi tted in place. Vibrating wheels are to be replaced
immediately.
6. Operation
6.1 Charging the Li battery pack (Fig. 1a-1b)
1. Remove the battery pack (6) from the handle,
pressing the pushlock button (8) downwards
to do so.
2. Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Insert the power plug of the charger
(7) into the mains socket outlet. The green
LED will then begin to fl ash.
3. Push the battery pack onto the battery char-
ger.
In section 10 (Charger indicator) you will fi nd a
table with an explanation of the LED indicator on
the charger.
If the battery pack fails to charge, check for the
following:
•
voltage at the power socket
•
whether there is good contact at the charging
contacts of the charging unit
