ORIGINAL INSTRUCTIONS
EN
Safety, performance, and dependability have been given top
priority in the design of your trim router.

INTENDED USE

The trim router is intended to be used only by adults who
have read and understood the instructions and warnings
in this manual, and can be considered responsible for their
actions.
The product is intended for precision woodworking tasks.
The product is ideal for shaping the edge onto wood and
trimming laminates.
The product should only be used in well-ventilated areas.
The product is intended for consumer use only. Do not use
the product for any other purpose.
WARNING! Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
TRIM ROUTER SAFETY WARNINGS
■ Use clamps or another practical way to secure and
support the workpiece to a stable platform. Holding
the work by your hand or against the body leaves it
unstable and may lead to loss of control.
■ Do not switch on the product again after it has stalled.
Switching it on again, can cause a kickback with high
reaction force. Determine why the product has stalled
and rectify it, paying heed to the safety instructions. If
necessary, remove the insertion tool.
■ Use only rotary cutting bits of the correct shank diameter
for the collet mounted.
■ Use only rotary cutting bits suitable for the speed of the
product.
■ Use the dust collection device and connect a dust
extraction vacuum when operating the product.
■ Injuries may be caused, or aggravated, by prolonged
use of a tool. When using any tool for prolonged periods,
ensure you take regular breaks.
■ Ambient temperature range for tool during operation is
between 0 °C and 40 °C.
■ Ambient temperature range for tool storage is between
0 °C and 40 °C.
■ The recommended ambient temperature range for the
charging system during charging is between 10 °C
and 38 °C.
ADDITIONAL BATTERY SAFETY WARNINGS
■ To reduce the risk of fire, personal injury, and product
damage due to a short circuit, never immerse the tool,
battery pack, or charger in fluid or allow fluid to flow
inside them. Corrosive or conductive fluids, such as
seawater, certain industrial chemicals, and bleach or
bleach-containing products, etc., can cause a short
circuit.
■ Ambient temperature range for battery during use is
between 0 °C and 40 °C.
■ Ambient temperature range for battery storage is
between 0 °C and 20 °C.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local and national
provisions and regulations.
Follow all special requirements on packaging and
labelling when transporting batteries by a third party.
Ensure that no batteries can come in contact with other
batteries or conductive materials while in transport by
protecting exposed connectors with insulating, non-
conductive caps or tape. Do not transport batteries
that are cracked or leaking. Check with the forwarding
company for further advice.
KNOW YOUR PRODUCT
See page 43.
1. Depth scale
2. Battery port
3. On/Off switch
4. Variable speed dial
5. Motor housing
6. Zero reset
7. Micro depth adjustment knob
8. Motor release lever
9. Chip shield
10. Quick-release lever
11. Removable base
12. Handle, insulated gripping surface
13. Vacuum adaptor
14. Spindle lock
15. Hole
16. Collet nut
17. D-shaped subbase
18. 6 mm / 6.35 mm collet
19. Wrench
20. Straight bit
21. Edge guide
22. Guide bars
23. Operator's manual
24. Battery pack
25. Charger
MAINTENANCE
■ The product should never be connected to a power
supply when assembling parts, making adjustments,
cleaning, performing maintenance, or when the product
is not in use. Disconnecting the product from the power
supply will prevent accidental starting that could cause
serious injury.
■ When servicing, use only original manufacturer's
replacement parts, accessories, and attachments. Use
of any other parts may create a hazard or cause product
damage.
