Dorman 604-114 Instructions De Montage

604-114
HVAC AIR DOOR
ACTUATOR
BEFORE YOU BEGIN:
• Always wear proper safety
equipment when performing repairs.
• Ensure at your point of purchase
that this part fits your exact
vehicle configuration.
• Reference the appropriate service
manual for your vehicle. If you do
not have a service manual, and do
not have the training or experience
to perform the necessary
procedures correctly, seek the
services of a qualified technician.
NEED HELP?
Please call our Technical Support
team for assistance from our team of
certified automotive experts.
1-866-933-2911
© 2024 No reproduction in whole or in part without prior written approval.
604-114_Tech-Note
NOTE: Please ensure that you have the correct part for your specific vehicle year,
make, model, configuration and position before installing and performing
this procedure. You can find complete application and fitment data on our website:
https:/ /www.dormanproducts.com/p-45323-604-114.aspx or scan the QR
code below.
WARNING: Failure to follow this procedure exactly could cause immediate failure of
the new air door actuator. Please read each step carefully before starting.
CALIBRATION
With a scan tool that can calibrate the HVAC control module on applicable vehicles:
1. With ignition off, replace faulty air door actuator. Make sure HVAC remains off before
installation of new actuator.
2. Connect a scan tool to OBD-II port.
3. Turn vehicle to key on, engine off.
On the scan tool, follow prompts for recalibrating all HVAC control modules. Do not adjust
4.
the climate controls until calibration is complete.
5. Wait 60 seconds. Calibration should now be complete. To verify, check that air is coming
out of selected vents.
Without a scan tool:
1. Disconnect negative battery cable. This is critical to start the relearn process.
Turn vehicle to key on, engine off and wait 5 minutes.
2.
3. Turn key to off position.
4. Replace faulty air door actuator.
5. Reconnect negative battery cable.
6. Turn vehicle to key on, engine off. Do not adjust any settings in the vehicle for five minutes
so that the vehicle can perform the calibration procedure properly.
7. Calibration should now be complete. If performed correctly, you should hear air door
actuators cycle, and air should come out of selected vents.
8. If calibration procedure does not happen after Step 6, there may be another failure in the
system. Contact an HVAC service professional to further diagnose the issue.
Dorman Products, Inc. Corporate Office and Customer Service: 1-800-523-2492.
Disclaimer: It is impossible in these instructions to account for all possible circumstances or situations that you may experience when at-
tempting to install this product. Please consult with a qualified auto technician before attempting to perform any work you are not qualified to
do. Automobiles can be hazardous to work on; be sure to take all necessary safety precautions. Failure to do so may result in property damage
or personal injury. Certain motor vehicle standards and performance requirements may apply to your motor vehicle (such as Federal Motor
Vehicle Safety Standards by the National Highway Traffic Safety Administration). Be sure that your work is performed in accordance with such
standards and that you do not disable any motor vehicle safety feature.
PAGE 1 OF 3
