7. Thread (4) threaded rods (supplied) into faceplate with a
hex nut (supplied) on each rod at the faceplate, left loose to
tighten later after adjustment. Thread (4) hex nuts (supplied)
onto each rod approximately 1/2" past finished wall depth.
Place (4) washers (supplied) on last as the toilet will mount
against these.
Hex Nuts
Hex Nuts
Washer
Washer
Threaded Rod
Threaded Rod
Threaded Nipples
Threaded Nipple
8. Install threaded nipple with thread sealant (supplied by others)
until snug.
9. Adjust the carrier mounting studs to extend approximately
2 1/4"(57) beyond the finished wall. Adjust the back-up nuts
flush with the finished wall, with the back-up washers outside
the wall. When properly positioned, the back-up washers
create a 1/16"(2) gap between the back of the bowl and the
face of the finished wall.
10. After threaded nipple and threaded rods are installed through
the wall and system has been properly pressure tested (per
industry standards); measure and mark the coupling 5/16" off
the finished wall. Cut the nipple and deburr before installing
Finished
Faceplate
toilet.
Wall
Assembly
Carrier
Back-Up Nut
Fitting
& Washer
Finished Wall
Finished Wall
Bowl
Gasket
ABS
Oval Fitting
Nipple
Gasket
Compression
Cut Nipple so
Cut Nipple so that
it Extends 5/16"
that it Extends
Past the Finished Wall
Flange & Gasket
5/16" Past the
Finished Wall
11. Remove the adhesive backing from both sides of the bowl
12. Install the four chrome cap nuts and plastic washers to
Note: It is common industry practice for three cap nuts to be
Bowl Gasket
Bowl Gasket
Bowl Gasket
3
gasket. Adhere the gasket to the back of the bowl, centered
around the bowl outlet. Install the bowl onto the carrier,
making sure the bowl gasket is properly seated against the
nipple.
secure the bowl.
fully tightened, and the fourth left hand tight. This reduces
potential stress that can cause the bowl to crack under
heavy loading.
Back-Up Nut
Back-Up Nut
& Washer
& Washer
Bowl
Gasket
Finished Wall
Finished Wall
CARRIER
CARRIER
FITTING
FITTING
Threaded
Threaded
Bowl
ABS Nipple
ABS Nipple
Gasket
Oval Fitting
Oval Fitting
Gasket
Gasket
