BO600RP/W/RH, BO900RP/W, P300RP/W, P600RP/W
EN
For 1-Maglock Handles Only
Example N°1: Exit button only (VHLD timer optional)
Voltage 12Vdc
or 24Vdc
ADC
1 x 300KG magnetic locks
Example N°2: Access Control + Exit Button
Access
Control
Voltage 12Vdc
or 24Vdc
ADC
For 2-Maglock Handles Only
Example N°1: Exit button only (VHLD timer optional)
Voltage 12Vdc
or 24Vdc
ADC
BO600RP / BO600W RANGE
Vertical & horizontal architectural handles
Exit
Button
P300 RANGE
Exit
Button
Unit
P300 RANGE
1 x 300KG magnetic locks
Exit
Button
2 x 300KG magnetic locks
12Vdc
MAGNETIC LOCK
N°1
12Vdc
MAGNETIC LOCK
N°2
24Vdc
12Vdc 24Vdc
24Vdc
7
