6KW, 15KWh
NOTICE: It's not applied for common battery when expanding the output power with 2 units. External
battery module only connects to its integrated main unit.
Step 2: Connect extension port on the battery modules with RJ11 cables (supplied in the external battery
module). After wiring installation is complete, set up ID for each battery module. The ID code for each
battery module MUST be unique. Not the same number for 2 battery modules in parallel system. Refer below
chart for the details.
NOTE: ID Switch indicates the unique ID code for each battery module. It's required to assign a unique ID to
each battery module for normal operation. From number 0 to 1, the number can be random, no particular
order. Maximum 2 battery modules can be operated in parallel.
Expand Battery Capacity
3KW, 5.0KWh
3KW, 7.5KWh
67
