1
Remove the top hinge cover.
Lift the door upwards to disengage it from the middle hinge,
put the door to one side and lay it down gently on a padded
2
surface.
Using a screwdriver, dismantle from the middle hinge, lift the
freezer door upwards to disengage it from the lower hinge.
Put the door to one side and lay it down gently on a padded
3
surface.
Take out the hinge pin out, rotate the hinge 180 degrees,
reverse and reinstall it to the opposite side, Swap over the
4
position of the lower hinge and the adjustable leg to the other
side of the cabinet.,
Remove the hinge pin that is in the bottom of the fridge and
freezer door. At the other side of fridge and freezer door,
5
insert the replacement hinge pin that is supplied with the
appliance inside the parts bag.
Place the freezer door on the lower hinge, making sure that
the hinge pin is inserted in the hole at the bottom of the
freezer door, put the middle hinge back on the cabinet,
6
making sure that it is on the opposite side from it original
position.
Place the fridge door on the middle hinge, making sure that
the hinge pin is inserted in the hole at the bottom of the fridge
7 door. Place the top hinge on the fridge door, fixing the screw
and cover.
