If the water supply is to be exclusively used for the Station, follow
the steps below.
• Remove the cap from the angle valve and install the 3/8 inch to 1/2
inch reducing connector. Align the internal thread end of the installed
reducing connector with the angle valve and connect them. Use a
wrench to tighten the connection.
• Seal the external thread end of the T-joint connector with the provided
cap plug.
• Close the T-joint connector, open the angle valve, and perform a leak
test.
Shared Water Supply to the Station
If the water supply is to be shared by the Station and other
appliances, follow the steps below.
• Install the 3/8 inch to 1/2 inch reducing connectors to both ends of
the T-joint connector.
• Use a wrench to dismantle the existing water pipe from the angle
valve. Align the internal thread end of the T-joint connector with the
angle valve, and connect them. Use a wrench to tighten the connection.
• Align the original water pipe with the external thread end of the T-joint
connector and connect them.
• Close the T-joint connector, open the angle valve, and perform a leak
test.
(4) Water Pressure Check
After installing the T-joint connector, test the water pressure.
Water Pressure Requirement: 0.1-1.0Mpa
(5) Assemble the Pipes
Place the Station near the installation position.
① Install the Clean Water Pipe
• Assemble the check valve properly with the clean water pipe. Cut the
clean water pipe at the point 10 cm away from the pressure relief valve
end and assemble the check valve parts in sequence as signed by the
arrows on the parts, in align with the direction of the pressure relief
EN
14
valve.
• Take out the clean water pipe assembly and insert the end with the
pressure relief valve into the T-joint connector.
• If the length of the clean water pipe needed is less than 4 meters,
dismantle the 1/4 inch hard elbow and cut a suitable length of the clean
water pipe.
• Install the 1/4 inch hard elbow by inserting it into the 1/4 quick-
connect elbow component of the Station.
② Install the Dirty Water Pipe
• Take out the dirty water pipe assembly and insert the 3/8 inch hard
elbow into the outlet pipe straight connector on the Station.
• Cut the other end of the dirty water pipe to a suitable length, insert it
into the drainage system, and secure it.
(6) Water and Electricity Test
• Release the valve of the T-joint connector and connect the power
supply to the Station.
• After the Station is successfully started up and water is supplied,
place the robot in the Station, and double press the Auto button to start
a Station self-cleaning process.
• After the Mop Washing Tray is filled with clean water, wait for 10
seconds, and check if the water can be automatically refilled and
drained.
• Make sure there is no leakage at all joints.
(7) Pipeline Arrangement
Wrap the clean water pipe and dirty water pipe together with the water
pipe decorative case.
(8) Installation Completion
Place the Station in its final installation position.
• Clean up the site and place the robot back into the Station.
• Run a whole-house cleaning task to confirm if the system operates
well.
