1.
General information
The relevant accident prevention regulations in accordance with BGV C22 must be observed for all work.
Furthermore, the relevant regulations and standards, such as DIN 18300 "Earthworks" and DIN 4124 "Ex-
cavations and trenches", must be observed during installation, assembly and repair.
For all work on the system or system components, the entire system must always be shut down and secured
against unauthorised restarting.
2.
Technical data
EcoFlow Control for Platin XL/XXL
EcoFlow Con-
trol set S
Order no.
369067
Drain size
1
DN 200
Dimensions
(640 x 200 x
(LxWxH)
200) mm
Flow rate
4.0 - 6.9 l/s
EcoFlow Control for Carat XL/XXL
EcoFlow Con-
trol set S
Order no.
369073
Drain size
1
DN 250
Dimensions
(660 x 250 x
(LxWxH)
250) mm
Flow rate
4.0 - 6.9 l/s
1
The outlet pipe must be designed with the specified nominal diameter and have a minimum length of 1000 mm. The pipe may then be reduced by a
maximum of one nominal width.
2
Transition pipe DN 200 to DN 250 included in the installation package. Outlet pipe must be continued in DN250 (see )
mail@graf.info
www.graf.info
1. General information
There is an increased risk of slipping when walking on the system in
frosty and wet conditions!
GRAF offers an extensive range of accessories, all of which are compati-
ble with each other and can be expanded into complete systems. The
use of accessories not approved by GRAF will invalidate the war-
ranty/guarantee.
EcoFlow Con-
EcoFlow Con-
trol set M
trol set L
369068
369069
DN 200
DN 200
(670 x 200 x
(700 x 200 x
200) mm
200) mm
7.0 - 8.9 l/s
9.0 - 10.4 l/s
Table 1: Technical data EcoFlow Control for Platin XL/XXL
EcoFlow Con-
EcoFlow Con-
trol set M
trol set L
369074
369075
DN 250
DN 250
(690 x 250 x
(720 x 250 x
250) mm
250) mm
7.0 - 8.9 l/s
9.0 - 10.4 l/s
Table 2: Technical data EcoFlow Control for Carat XL/XXL
6 / 20
EcoFlow Con-
EcoFlow Con-
trol set XL
trol set 2XL
369070
369071
DN 200
DN 250
(720 x 200 x
(750 x 200 x
200) mm
200) mm
10.5 - 13.9 l/s
14.0 - 17.9 l/s
EcoFlow Con-
EcoFlow Con-
trol set XL
trol set 2XL
369076
369077
DN 250
DN 250
(740 x 250 x
(770 x 250 x
250) mm
250) mm
10.5 - 13.9 l/s
14.0 - 17.9 l/s
1
EcoFlow Con-
trol set 3XL
369072
2
DN 250
2
(760 x 200 x
200) mm
18.0 - 20.0 l/s
EcoFlow Con-
trol set 3XL
369078
DN 250
(780 x 250 x
250) mm
18.0 - 20.0 l/s
