HANDLING AND INSTALLATION
To assemble appliances in banks (side by side)
proceed as described below.
Pull off the knob (A).
1)
Undo the screws (C) and remove the control
2)
panels (B).
Apply masking tape to the edges to be
3)
placed side by side.
Apply food-approved sealant to the edges to
4)
For appliances installed in banks, an optional
kit is available with the supporting frame and
some trims.
Screw the feet (A) onto the structure in the con-
nection points.
3036231_inst_GB
ASSEMBLY APPLIANCES IN BANKS
INSTALLING ACCESSORIES
be placed side by side.
Place the appliances side by side.
5)
Connect the appliance using the screws and
6)
nuts (D-E).
Remove the excess sealant and the masking
7)
tape.
Replace the control panels (B) and the knobs
8)
(A) on completion of the operation.
ENGLISH
9
