REPAIR PARTS
Rail Assembly Parts
2
Installation Parts
1
L O C
K
L I G
H T
6
9
12
1
3
5
4 2
3
7
8
11
10
13
5
4
KEY PART
NO. NO.
1 4A1008
2 41A4813
3 41A3489
4 1707LMC
6
1708LMC
1710LMC
5 41D3484
6 83A11-2
KEY PART
NO. NO.
1 398LMC
2 373PC
3 10A19
4 10A33
5 29C151
6 41A2828
7 41B4494-1
8 41A5047-1
9 41A4353-1
10 41A5034
11 178B34
12 178B35
13 41A5266-1
41A2770-13 Installation hardware bag
114A3405
35
DESCRIPTION
Master link kit
Chain pulley bracket
Complete trolley assembly
One-piece rail 7' (2.1 m)
One-piece rail 8' (2.4 m)
One-piece rail 10' (3 m)
Full chain assembly
Rail grease
DESCRIPTION
Smart Control Panel™
3-button remote
3V2016 lithium battery: led and opener
3V2450 lithium battery: proximity
switch
Remote control visor clip
Emergency release rope & handle assy.
2-Conductor bell wire, white &
white/red
Door bracket w clevis pin & fastener
Header bracket w/clevis pin & fastener
Safety sensor kit (receiving and
sending eyes) with 3' (.9 m)
2-conductor bell wire
Straight door arm section
Curved door arm section
Safety sensor brackets (2)
NOT SHOWN
(includes hardware listed on page 5).
Owner's manual
