STANDARD MOUNT AND MEASUREMENTS
B
C
D
Figure 3
A. 25" (635 mm)
1
B.
/
" (12.7 mm) minimum
2
11
C. 19
/
" (500.06 mm)
16
D. 36" (914.40 mm)
E. 24" (609.60 mm)
1
F. 34
/
" (876.30 mm)
2
Figure 3 represents a typical standard cabinet.
a
F
E
Move oven location downward for
extended countertops
Extended countertops
If installed in custom cabinets with extended countertops, take
into account visibility and access to controls. See Figure 4.
E5
Figure 4
