CLEARANCES AND DIMENSIONS
• Use the dimensions shown in Figure 1. Given dimensions
provide minimum clearance. Locate electrical outlet in the
shaded area in the upper left-hand corner of the cutout.
See Figure 9.
• Contact surface must be solid and level. Pay special atten-
tion to the floor on which the Convection DrawerMicro oven
will sit. The floor of the opening should be constructed of
plywood strong enough to support the weight of the oven
(about 125 pounds).
• Check location where the Convection DrawerMicro oven
will be installed for proper electrical supply.
• Your oven can be built into a cabinet or wall as a stand-alone
unit.
• The required clearance of the floor between the wall oven
and the Convection DrawerMicro oven is a minimum of
2-inches.
• The Convection DrawerMicro oven interior will easily
accommodate a 9" x 13" oblong dish or a bag of microwave
popcorn.
• The oven can also be mounted flush. See Figures 5, 6 and 7.
E3
