WARNING!
The door is heavy.
CAUTION!
Carefully handle the glass, especially
around the edges of the front panel. The
glass can break.
1. Make sure the appliance is cold.
2. Fully open the door.
3. Press the clamping levers
door hinges.
A
4. Close the oven door to the first opening
position (at approximate angle: 70°).
5. Hold the door with one hand on each side
and pull it away from the oven at an
upwards angle.
6. Put the door with the outer side down on
a soft cloth on a stable surface.
7. Hold the door trim
the door at the two sides and push
inwards to release the clip seal.
2
B
8. Pull the door trim to the front to remove it.
9. Hold the door glass panels on their top
edge one by one and pull them up out of
the guide.
on the two
A
on the top edge of
1
10. Clean the glass panel with water and
soap. Dry the glass panel carefully. Do
not clean the glass panels in the
dishwasher.
After cleaning, do the above steps in the
opposite sequence. Install the smaller panel
first, then the larger and the door.
Make sure that the glass panels are inserted
in the correct position otherwise the surface
of the door may overheat.
11.12 Replacing the lamp
WARNING!
Risk of electric shock.
The lamp can be hot.
1. Turn off the appliance and wait until it is
cold.
2. Disconnect the appliance from the mains.
3. Place the cloth on the oven floor.
Top lamp
1. Turn the glass cover to remove it.
2. Remove the metal ring and clean the
glass cover.
3. Replace the lamp with a suitable 300 °C
heat-resistant lamp.
4. Attach the metal ring to the glass cover
and install it.
Side lamp
1. Remove the left shelf support to get
access to the lamp.
ENGLISH
21
