1. WARNINGS
This manual for MATRIX series contains important information concerning personal safety.
An incorrect installation or an improper use may lead to severe injuries.
Read carefully and pay particular attention to the safety sections marked by the yellow triangle
The installation of automatic doors, gates and barriers must comply with the Machinery Directive
2006/42/CE and EN 12453 regulation and performed by qualified personnel
Make sure the area is clear from flammable gases and/or electromagnetic interferences: it could
lead to very dangerous injuries.
Switch the power and batteries OFF before any intervention/alteration.
After installation, packaging and waste materials (cardboard, plastic, metal parts etc.) must be kept
away from children as they could be potentially harmfull.
Use only original spare parts. Any alteration to the system is prohibited.
Proteco Srl will not respond in case of using additional and/or fake spares
Before commissioning the system, deliver the last pages of this manual to the user (section 5.
END USER'S TIPS starting from page 7).
Proteco S.r.l. reserves the right to make changes to the product without notice.
2. CONTENT
ARC02 - rev.1.1_03_2021
DESCRIPTION
1 Adapter curved arm
2
Adapter straight arm
3 Screw TE 5x45
4 Flat washer D5
5 Self locking bolt M5
6 Screw TE 8x50
7
Flat washer D8
8 Self locking bolt M8
9 Spacer 28x12
10 Bush 25x18
11 Metal spacer D10
12
Plastic spacer 12x11
.
UNITS
1
2
4
4
4
3
3
3
1
4
4
4
3
