DESCRIPTION
KNOW YOUR BRUSH CUTTER & GRASS TRIMMER (Fig. 1)
The safe use of this product requires an understanding of the information on the tool and in this operator's
manual, as well as knowledge of the project you are attempting. Before using this product, familiarize yourself
with all operating features and safety rules.
1.MCDU (Multiple control display unit)
2.Battery Socket
3.Main trigger & Lock off button
4. Loop handle
5. Shaft
6. Guard
7. Trimmer head
WARNING:
Never operate the tool without the guard firmly in place. The guard must always be on the
tool to protect the user.
LOOP HANDLE OR BIKE HANDLE
For easy control of the trimmer during cutting.
8. 3T blade
9. Socket spanner
10. S5 Allan key
11. S4 Allan key
12. Adjustment knob
13.Bike handle
14.Spring
8
