S+S Regeltechnik HYGRASGARD KFTF - Modbus - T3 Notice D'instruction page 8

G U
HYGRASGARD
Schematic diagram
Plug for
display
1 2 3 4 5 6 7 8
SHD
DIP A: Bus address
DIP B: Bus parameters
(Baud rate, parity...)
Telegram indicator
Reception (LED green)
Error (LED red)
Manual offset adjustment
The sensors are pre-set and calibrated at the factory.
For subsequent adjustment of the measured value,
there are two offset potentiometers (A and B) available.
Range of adjustment approx. ± 5 °C ⁄ ± 9 °F (A) or ± 10 % RH (B).
Type ⁄ WG01
KFTF - Modbus - T3
K F T F - M o d b u s -T 3
K F T F - M o d b u s -T 3 LCD
KFTF - Modbus - T3
K F T F - 2 0 - M o d b u s -T 3
K F T F - 2 0 - M o d b u s -T 3 LCD
Optional:
Note:
ACCESSORIES
KA2 -Modbus
LA -Modbus
SF - M
SF - K
MFT - 20 - K
®
KFTF (20) - Modbus-T3
HYGRASGARD
ON
A offset B
1 2 3 4 5 6 7 8
address
ON
DIP B
1 2 3 4 5 6
mode
SHD
LED (internal status)
Offset correction
Shielding
Measuring Range ⁄ Readout
Humidity (switchable)
0...100 % RH (default)
0... 80 g ⁄ kg (MV)
0... 80 g ⁄ m³ (AH)
0... 85 kJ ⁄ kg (ENT.)
0...+50 °C (DP)
(5 x as above)
(5 x as above)
(5 x as above)
Cable connection with M12 connector according to DIN EN 61076-2-101
shortened protective tube PLEUROFORM
Protective tube made of stainless steel
System of units SI (default) or imperial (can be changed via Modbus).
Communication adapter (USB/RS485) for system connection
Line termination device (with terminating resistor) as an active bus termination
Metal sinter filter, Ø 16 mm / 0.63 in, L = 32 mm / 1.26 in, exchangeable,
stainless steel l V4A (1.4404)
Plastic sinter filter, Ø 16 mm / 0.63 in, L = 35 mm/ 1.38 in, exchangeable
(included in the scope of delivery)
Mounting flange, plastic (included in the scope of delivery)
® Pin assignment
xx - Modbus - T3
(M12 option)
DIP A
Output
Temperature
–35...+80 °C / Modbus
–31...+176 °F
(1 x as above) Modbus
(1 x as above) Modbus
(1 x as above) Modbus
TM
, NL = 100 mm / 3.4 in
8
MALE
2
3 5 1
4
1
+UB
2
Modbus A
3
–UB GND
4
Modbus B
5
Shield
Item No.
Display
(± 2,0 %)
1 201-32C 6- 1000- 029
■ 1201- 32C6- 1400- 029
(± 1,8 %)
1201-32C 6- 1000- 030
■ 1201- 32C 6-1400- 030
1906- 1200- 0000-100
1906- 1300- 0000-100
7000- 0050- 2200-100
7000-0050- 2310- 000
7100- 0030-4000 -000
Rev. Data - V41
®
HYGRASGARD
xx - Modbus - T3
FEMALE
2
1 5 3
4
on request
on request
on request
