Installation instructions Wilo-Stratos GIGA2.0-I, Wilo-Stratos GIGA2.0-D
All manuals and user guides at all-guides.com
Description of the pump
Property
Nominal diameters DN
Pipe connections
Max. permissible operating
pressure
Permissible min./max. fluid
temperature
Permissible fluids
Table 5: Technical data
1)
TN and TT power supplies with earthed live wires are not permitted.
2)
For more detailed, product-specific information such as power consumption, dimen-
sions and weights, refer to the technical documentation in the catalogue or Wilo-Select
online.
3)
Over Voltage Category III + Surge Protective Device/Metall Oxid Varistor
4)
Average value of the sound-pressure levels on a spatially rectangular measuring sur-
face at a distance of 1 m from the pump surface in accordance with DIN EN ISO 3744.
5)
For more information about permissible fluids, see the "Fluids" section.
Additional information
CH
Heating pumps
Fluids
Water-glycol mixtures or fluids with a different viscosity than pure water increase the
power consumption of the pump. Only use mixtures with corrosion protection. Observe
the relevant manufacturer's specifications!
ƒ
The fluid must be sediment-free.
ƒ
Wilo's approval must be obtained for the use of other fluids.
ƒ
Mixtures with a proportion of glycol of > 10 % influence the Δp-v characteristic
curve and the flow calculation.
ƒ
The compatibility of the standard seal/standard mechanical seal with the fluid is
generally given under normal system conditions.
Special circumstances may require special seals, for example:
–
solids, oils or EPDM-attacking substances in the fluid,
–
air content in the system, etc.
Observe the safety data sheet for the fluid to be pumped!
NOTICE
When using water-glycol mixtures, the use of an S1 variant with a corresponding
mechanical seal is generally recommended.
Value
Stratos GIGA2.0-I/
Stratos GIGA2.0-D:
40/50/65/80/100/125
Flanges PN 16
16 bar (up to +120 °C)
13 bar (up to +140 °C)
-20 °C ... +140 °C
Heating water in accordance
with VDI 2035 Part 1 and
Part 2
Cooling/cold water
Water-glycol mixture up to
5)
40 % Vol.
Water-glycol mixture up to
50 % Vol.
Heat carrier oil
Other fluids
Permissible fluids
Heating water
(in accordance with VDI 2035/VdTÜV Tch 1466/CH: in ac-
cordance with SWKI BT 102-01)
...
No oxygen binding agents, no chemical sealants (ensure
closed system from corrosion perspective according to VDI
2035 (CH: SWKI BT 102-01); rework leaky points).
en
Note
EN 1092-2
Depending on the fluid
Standard version
Standard version
Standard version
Only for special version
Only for special version
Only for special version
