Dreame Z30 Ultra Mode D'emploi page 21

Care & Maintenance
Tips:
• Always use genuine parts to keep your
warranty from being void.
• If the filter or nozzle becomes clogged,
the vacuum will stop working shortly
after being turned on. Clear the tube to
restore functionality.
• Before cleaning the dust cup, please
confirm that the plug is disconnected
and keep the vacuum's power button in
the off position.
• If the vacuum is not used for an
extended period, fully charge it, unplug
the power cord, remove the battery,
and store it in a cool, low-humidity
environment away from direct sunlight.
To avoid over-discharging the battery,
recharge the battery at least once every
three months.
Cleaning the Vacuum
Wipe the vacuum with a soft dry cloth.
Cleaning the Dust Cup, Pre-
Filter, and Cyclone Assembly
1. Press the dust cup bottom cover release
button, then empty the contents.
Fig. F-1
2. Press the dust cup release button and
remove it from the vacuum.
Fig. F-2
3. Remove the pre-filter first, and then
rotate the cyclone system to lift it out.
Fig. F-3
4. Rinse the cyclone assembly, pre-filter,
and dust cup until they are clean. After
washing, air dry for at least 24 hours.
Fig. F-4
Note:
• Please clean the dust cup as needed.
• It is recommended to clean the cyclone
system and pre-filter at least once every
3 to 4 months.
Cleaning the Filter
1. Remove the dust cup as shown in the
figure.
Fig. F-5
2. Remove the filter from the vacuum by
pulling it down in the direction shown in
the figure.
Fig. F-6
3. Rinse the filter with rotating it 360°.
Lightly tap the filter several times to
remove any debris caught in it.
Fig. F-7
4. Allow the filter to air dry for 24 hours.
Fig. F-8
Note:
• Only use clean water to wash the filter.
• Do not use detergent.
• Do not attempt to clean the filter with a
brush or finger.
• It is recommended to clean the filter once
every 4 to 6 months.
Cleaning the Illumination
Omni-Brush
1. As shown in the figure, push the lock
down to remove the roller from the
brush.
Fig. F9
2. Use scissors to cut off the hairs and
fibers that get stuck on the brush roller.
Wipe the dust from the notch, the
sealing strips on both sides and the
transparent cover with a dry cloth or
paper towel.
Fig. F10
3. When the brush roller is dirty, rinse it
with clean water until it is clean. Then
stand the brush roller upright for at
least 24 hours until it is fully dry.
Fig. F11
EN
6
