Product Overview
EN
Accessories
1. Soft Dusting Brush
2. Flexible Adapter
3. Rotating Soft Dusting Brush
4. Motorized Mini-Brush
5. Charger
6. Extension Rod
7. Combination Tool
8. Extension Hose
9. Illumination Omni-Brush
10. C harging & Storing Mount
11. P et Deshedding Tool
Fig. A
Note: The illustrations in this manual are
indicative only. The actual product may
differ.
Component Name
Vacuum Body
1. Dust Cup
2. Dust Cup Release Button
3. Dust Cup Bottom Cover Release Button
4. Battery Pack Release Button
5. Display Screen
6. Power Button
7. Suction Level Switch
8. Battery Status Indicator
9. Antistatic Contact
Fig. B-1
Installation
Installing the Accessories
Note:
• It is not recommended to use the
motorized mini-brush with the extension
rod.
• Please install the accessories according
to the actual cleaning needs.
3
• It is recommended to use the flexible
adapter when cleaning the low-lying
furniture and not recommended to be
connected to the vacuum body all the
time for daily floor cleaning.
Fig. C-1
Charging
Fully charge the vacuum before
using it for the first time.
Place the vacuum cleaner on the
charging & storing mount as shown in the
illustration, and then connect the charger
between the charging & storing mount
and the power supply. The battery status
indicator will blink while charging.
Note:
• The flexible adapter cannot be
connected to the vacuum body while
charging.
• When the charging contacts are dirty,
please gently wipe them with a dry
cloth.
• The vacuum cannot be used while
charging.
• When fully charged, the battery status
indicator will turn off after 5 minutes and
the vacuum will enter the power saving
mode.
• This will take about 4 hours. Vacuuming
at Turbo mode for a prolonged period
will cause the battery to heat up, which
increases charging time. Allow the
vacuum to cool down for 30 minutes
before charging it.
Fig. D-1
Battery Status Display
1. Battery Status Indicator
Blinking white
Solid white
Off
