Parameter functioning
Always return to
Your door is in operating condition.
■
Operating
information
Event codes
Fault codes
All manuals and user guides at all-guides.com
Motor operating time
Each press on the
1 second increments.
Examples:
- 20 seconds for height of door up to 2500mm
- 23 seconds for height of door between 2500mm and 3000mm
- 30 seconds for height of door between 3000mm and 4000mm
Time for reclosing the door
Inactive parameter in the sequential mode.
Time before motor reversion
Each press on the
1 second increments.
00: the door re-opens immediately in the event of an
obstacle detection.
Area lighting time after cycle end
Each press on the
1 minute increments (10 minutes max.)
parameter with key
The LCD screen will provide a visual indication providing rapid diagnosis
relating to the operating modes of the Axroll.
Permanent contact on "START" input
Safety fault at opening (contact always open)
Safety fault at closing (contact always open)
ADMAP safety fault (contact always open)
Limit exceeded on 24V power supply
or button adjusts the time in
or button adjusts the time in
or button adjusts the time of
or .
Axroll waiting for a command
Opening door
Delay before closing the door
Closing door
Open cell hidden
Close cell hidden
ADMAP cell hidden
Door movement forced by keypad
Emergency stop triggered
Self-testing safety
Delay before motor reversion
Self-test failed on security input 1
Self-test failed on security input 2
Self-test failed on security input 3
(too many accessories connected)
Operating time "T0" too short or
motor end-limit not reached
= 80
20
23
30
= 05
= 00
= 02
